The new designed MEGATRON® MT 5100 inline homogeniser for Pilot Plant and Small Scale Production offers the following outstanding features:
• powerful and maintenance free high frequency three phase drive motor with 1.5 kW for continuous operation
• speed regulation by frequency inverter for up to 21‘000 rpm
• tip speed up to approx. 37 m/s (depending on the chosen dispersing generator and product properties)
• digital display for speed indication
• connection to a standard single phasewall socket is sufficient
• quiet drive system approx. 62 dB (A) (without load)
• Working chamber (one stage - for one dispersing generator) with single mechanical seal incl. quench liquid system and optional cooling / heating jacket can easily be attached to the drive unit by unique quick coupling
• 8 different and interchangeable dispersing generators (Rotor/Stator)
available for various applications max. throughputs of up to 65 l/min possible, depend on dispersing generator and product properties
• connectable to PC in combination with the optional “PC control†kit incl. free KINEMATICA software
• A variety of recirculating systems with piping and working tanks from
different materials and different sizes, pumps and process control can be offered to your specifc applications and working condition in the chemical, pharmaceutical and food industries - therewith the MT 5100 is also ideal for scale-up calculations.
